4.3.4

Motor current

The motor current is transferred via the input parameter
value. SIMOCODE pro always transfers the current here as a percentage of the set current
in a range from 0 to 1020%.
The
The
set current for the motor configured in SIMOCODE.
Note
The motor current is only calculated if the current measuring module is connected to the
SIMOCODE pro device and configured.
4.3.5

Device functions

Parameter DevFunc
The
and the configuration of further modules by reading the DS105. The data are relevant for:
● Device class
● Control function
● Status thermistor
● Status analog module
● Status temperature
● Status ground fault module
● Status voltage module
● Current measuring module
● Analog module
● Digital module
The structure of the
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
parameter calculates this as a percentage.
MotCurr
parameter calculates the motor current actually drawn in amps based on the
MotCurrE
parameter provides information about the parameterization of SIMOCODE pro
DevFunc
DevFunc
parameter can be found in the UDT "OPERATION".
Description of the blocks
4.3 MMOprtn block
as an unsigned 2-byte
PZDIn23
103
