Description of the blocks
4.6 Block for timestamping MMLog
Reference
Block parameter MMLog (Page 267)
Overview of the templates, control functions and blocks (Page 38)
Functions for all blocks (Page 72)
4.6.2
Parameterizable functions via the Feature connection MMLog
The modules of the library have an input named
responses of the block via this input.
The Feature Bits are assigned in the following order:
Table 4- 81
Feature.Bit
Feature.Bit1
Feature.Bit22
Feature.Bit24
Feature.Bit25
Feature.Bit26
The default setting is 0 in each case.
Note
Feature bit 26 will suppress the reading of DS 72, 73, 76, 77, 162. The parameters LogId1-
LogId21 and LogTm1- LogTm21 will not be updated.
4.6.3
Operating modes
The following operating modes are displayed on the block:
● Local
● ON
● Out of service (Oos)
184
Meaning of Feature.Bits
Meaning
Response for Out of Service mode
Update acknowledgment and error status of the alarm call
Activate local operator permission
Suppression of all messages
1 = Suppress reading of logbook data
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
. You can influence various
Feature
SIMOCODE pro PCS 7 Library V9.0
