● In the case of blocks with operator control or monitoring functions (for example,
faceplates), these signals are identified in the faceplate with the status for the simulation
as follows:
● The group status of the block is displayed in the status bar of the block icon and of the
operator block with the simulation status as follows:
● The interlocking functions of the block are activated in accordance with the input
parameter
● Auxiliary values (e.g. UserAna1) cannot be simulated.
● When the control function of the block can be manipulated, the read-back and feedback
values (for example,
settings
4.7.11

Monitoring functions

The monitoring function can be released or blocked via the operator in the faceplate.
The
activated:
●
Monitor = 1
●
Monitor = 0
If the block is in Local mode, no check is made for monitoring errors.
If the "Forward" / "Stop" command is output and no correct feedback signal is received within
the defined time (
output signal will issue the "Stop" command.
The monitoring time is specified in seconds. If the monitoring time is less than the sampling
time, the monitoring time will be calibrated to the sampling time. The time can be entered in
the faceplate in the expanded command area in day-hour-minute-second format.
The function is not available in Out of Service mode.
Note
The monitoring functions are functions of the block.
SIMOCODE pro nevertheless has its own functions for monitoring the on/off operations and
the switching state of the motor.
The monitoring functions of the block can come into conflict with monitoring functions
configured in SIMOCODE pro under certain conditions.
Once 'monitor' function is activated, the current monitoring time will be shown at
output parameter and the same will be shown in preview faceplate.
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
or deactivated
BypProt = 0
FbkFwd
parameter indicates whether the feedback for the monitoring function is
Monitor
(default): Monitoring function ON
: Monitoring function OFF
MonTiDynamic
BypProt = 1
) are adjusted according to the manipulation of the control
), the block will issue an error signal (
Description of the blocks
4.7 MMRevDhl motor block
.
MonDynErr
) and the
CurrMon
207
