Description of the blocks
4.3 MMOprtn block
Message block MsgEvId2
Table 4- 21 Output messages
Message Message
block No.
MsgEvId2
1
2
3
4
5
6
7
* W = Warning; S = AS, OS process control fault; A = Alarm
GenWarn and GenFlt block parameters
GenWarn
●
GenWarn.Value
●
GenWarn.ST
GenFlt
●
GenFlt.Value
●
GenFlt.ST
Message block MsgEvId2
Table 4- 22 Output messages
Message Message
block No.
MsgEvId2
1
2
3
4
5
6
7
8
* S = AS, OS process control fault
112
Block parameters Message text
GenWarn
$$BlockComment$$ Group warning:
@4W%t#MMOprtn_WRN@
GenFlt
$$BlockComment$$ Group fault:
@5W%t#MMOprtn_TRP@
CSFlt
$$BlockComment$$ Control system fault
CurWrnH
$$BlockComment$$ Warning I>
CurWrnL
$$BlockComment$$ Warning I<
CurTrpH
$$BlockComment$$ Trip I>
CurTrpL
$$BlockComment$$ Trip I<
is of the type
DigvalE
= 1 if the number indicating the cause of the warning is > 0.
displays the number indicating the cause of the warning.
is of the type (
DigvalE DigvalE.Value
= 1 if the number indicating the cause of the trip is > 0.
displays the number indicating the cause of the trip.
Block parameters
ExMsgOu1
ExMsgOu2
ExMsgOu3
ExMsgOu4
ExMsgOu5
ExMsgOu6
ExMsgOu7
ExMsgOu8
( : BOOL;
DigvalE.Value
: BOOL;
DigvalE.ST
Message text
$$BlockComment$$External message 1
$$BlockComment$$External message 2
$$BlockComment$$External message 3
$$BlockComment$$External message 4
$$BlockComment$$External message 5
$$BlockComment$$External message 6
$$BlockComment$$External message 7
$$BlockComment$$External message 8
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
: error number)
DigvalE.ST
: error number)
SIMOCODE pro PCS 7 Library V9.0
Message
class *
W
S
S
W
W
A
A
Message
class *
S
S
S
S
S
S
S
S
