Description of the blocks

4.3 MMOprtn block

4.3 MMOprtn block
4.3.1

Description of MMOprtn

Purpose of the block
The MMOprtn block supports the control functions in the Advanced Process Library (APL)
that are specific to SIMOCODE pro.
● Via the block, commands such as emergency start, test, trip reset are started because
these functions are not supported by the APL themselves.
● The block reads the data records.
● SIMOCODE data records are configured via the block.
Block icons and faceplates
The MMOprtn block faceplates can be displayed via the "Operation" button on the standard
view of the respectie APL block used in the template.
The block icon for the MMOprtn block can also be enabled at the CFC as described in
section 2.2
The status of the programmed control functions is displayed via the faceplates, e.g. motor
status, diagnostic information of the device.
Views
The MMOprtn block supports the following views:
● Batch
● Trend
● Alarm
● Preview
● Standard (Page 148)
● Limits (Page 150)
● Diagnostics (Page 152)
● Process image (Page 153)
Reference
Block parameter MMOprtn (Page 244)
Functions for all blocks (Page 72)
Overview of the templates, control functions and blocks (Page 38)
