Note
For Star-Delta starter and Star-Delta reverse starter, Change over pause time configured in
device should be added along with Feedback/Execution time for Star-Delta and
parameterized in ( < Dynamic monitoring time, MonTiDynamic = MonTiStatic).
1.8.3

Configuration with SIMATIC PDM

You can use the SIMATIC PDM software to configure the SIMOCODE pro C / S / V devices.
The devices are accessed via the PROFIBUS and PROFINET interface.
You can find information on configuration using the SIMATIC PDM software in the
documentation for SIMATIC PDM and SIMOCODE pro EDD.
Note
Transmission of modified device parameters is possible under the following conditions:
• The device is not in the SIMOCODE pro "remote" mode.
• No ON control command is active.
• No motor current is flowing.
1.8.4

Device type selection in HW Config

You can select the device type in the HW Config as follows:
1. Start the SIMATIC Manager.
2. Open the "Settings" menu via "Options → SIMATIC PDM → Settings".
The dialog box opens.
3. Enable "Select type when device is inserted in HW Config".
4. Confirm by clicking OK and close the dialog box.
5. Close SIMATIC Manager and integrate EDD using the SIMATIC PDM "Device Integration
Manager".
Note
SIMOCODE pro V PN
PCS 7 V8.1 and above support integration of SIMOCODE pro V PN devices using SIMATIC
PDM.
SIMOCODE pro PCS 7 Library V9.0
