4.3.21

Diagnostics information

The diagnostics information is communicated to WinCC for display in the faceplates.
The following diagnostics information is available for SIMOCODE pro devices and for
SIMOCODE pro PROFINET devices:
● Status diagnostics, output via the parameter output
● Event diagnostics, output via the parameter output
● Warning diagnostics, output via the parameter output
● Trip diagnostics, output via the parameter output
DiagSts – Status diagnostics
Table 4- 42
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
DiagSts – Status diagnostics for SIMOCODE pro devices
Meaning
General fault
General warning
Device OK
Bus OK
PLC/PCS OK
Motor current flowing
On <<
On <
Off
On >
On >>
Start active
Interlocking time active
Change-over pause active
Positioner runs in open direction
Positioner runs in close direction
Feedback closed (FC)
Feedback opened (FO)
Torque closed (TC)
Torque opened (TO)
Test position feedback (TPF)
Operational protection off (OPO)
Remote mode
Emergency start executed
Cooling down period active
Pause time active
Device check active
Phase sequence 1-2-3
Phase sequence 3-2-1
DM-F enabling circuit closed
Description of the blocks
4.3 MMOprtn block
DiagSts
Diag_Evt
Diag_Wrn
Diag_Trp
