Description of the blocks
4.3 MMOprtn block
Table 4- 48 DiagWrn2 – Warning diagnostics for SIMOCODE pro devices
Bit Meaning
0 AM1 open circuit
1 DM-F safety-oriented tripping
2 DM-F monitoring interval for mandatory testing - test required
3 DM-F feedback circuit
4 DM-FL simultaneity
11 EM open circuit
12 EM short circuit
Table 4- 49 DiagWrn2 – Warning diagnostics for PROFINET pro devices
Bit Meaning
5 TM2 level T >
6 TM2 sensor fault
7 TM2 out of range
8 AM2 level 0/4-20mA >
9 AM2 level 0/4-20mA <
10 AM2 open circuit
