Parameter
N_IntCwStrt
N_IntCCwStrt
EngyCon
OS_PermOut
OS_PermLog
Opst_Out
ST_Worst
Status1
ErrorNum
MsgErr1
MsgStat1
MsgAckn1
ReserveOut
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Data format Default setting
STRUCT –
Value: DINT 0.0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: DINT 0.0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: DINT 0.0
• •
ST: BYTE 16#80
• •
DWORD 16#FFFFFFFF
DWORD 16#FFFFFFFF
DWORD 16#00
BYTE 16#80
DWORD 16#00000000
INT -1
BOOL FALSE
WORD 16#00
WORD 16#00
WORD 16#00
A.5 Block parameter MMStat
Meaning
Internal Number of Starts motor Right
Internal No. of Starts motor Left
Energy Consumed in kWh
Operator Permission: Output for OS
Display of OS_Perm with settings changed by block
algorithm
Enabled operator stations
Worst Signal Status
Status word 1
Error number
1 = Messaging Error Occurs
ALARM_8P: Status Output
ALARM_8P: ACK_STATE Output
Reserved
Parameter
