Description of the blocks
4.2 Diagnostics block MMDiag
Auxiliary values
Table 4- 8
Message No.
1
2
3
4
5
6
7
8
9
10
The
● Message status
● Message error
● Message acknowledgment status
4.2.4

Driver generator

The "Generate Module Driver" function automatically inserts the MMDiag block into the
following organization blocks within the run sequence:
● OB1 (cyclic program)
● OB40 (process alarm)
● OB82 (diagnostics alarm)
● OB83 (pull/plug alarm)
● OB85 (program execution error)
● OB86 (rack fault)
● OB100 (warm restart)
The block is inserted behind the OB_DIAG1 / OB_DIAG1_PN block in the CFC chart.
The
inputs are configured via the information from HW Config.
96
Structure of the auxiliary values ALARM_8P
Auxiliary
value
1
2
3
4
5
6
7
8
9
10
, , and
MsgStat1 MsgAckn1
, ,
Rack_No Slot_No SubSlot_No
Block parameters Meaning
Subn1Id
ID of the primary subnet
Subn2Id
ID of the redundant subnet
Rack_No
Rack number
Slot_No
Slot number
ExtVa105
Auxiliary value 5, user-definable
ExtVa106
Auxiliary value 6, user-definable
ExtVa107
Auxiliary value 7, user-definable
ExtVa108
Auxiliary value 8, user-definable
ExtVa109
Auxiliary value 9, user-definable
ExtVa110
Auxiliary value 10, user-definable
parameters transfer the following information:
MsgErr1
, , ,
SubAddr DAddr LAddr
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
, , and
Subn1Id Subn2Id SubN_Typ
SIMOCODE pro PCS 7 Library V9.0
