4.1.10.17

Bumpless switchover to automatic mode

Number of the
Feature
Feature bit purpose
Specify whether bumpless switchover to automatic mode for valves, motors and dosing unit
can be enabled only if switching via the faceplate is in effect, or whether switching using
interconnectable inputs
The default setting is 0.
Bit = 0: The function "Bumpless switchover to automatic mode for valves, motors and
dosers" works when switching via the faceplate and switching using interconnectable inputs
AutModLi
Bit = 1: The "Bumpless switchover in automatic mode for valves, motors and dosers"
function only works for switching via the faceplate. Bumping switchover can be activated via
the inputs
4.1.10.18

Update acknowledgement and error status of the alarm

Number of the
Feature
Feature bit purpose
To determine if the acknowledgement and error status of the message call at the block
output should be updated.
The default setting is 0.
Bit = 0: The
updated. The block will run faster with this setting.
Bit = 1: The
from the lower level message blocks. The lower level message blocks are called every other
cycle as long as an acknowledgement is expected or error information is pending.
4.1.10.19

Activate local operator permission

Number of the
Feature
Feature bit purpose
To enable local permission for a technologic block.
The default setting is 0.
Bit = 0: Disabled
Bit = 1: Enabled.
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
bit: 21
AutModLi
and (
ManModLi ModLiOp
and
AutModLi ManModLi
bit: 22
, and
MsgErr MsgStat
, and
MsgErr MsgStat
bit: 24
and (
ManModLi ModLiOp
= 1).
( = 1).
ModLiOp
block outputs are set to the default settings and not
MsgAckn
block outputs are updated based on the feedback
MsgAckn
Description of the blocks
4.1 Functions for all blocks
=1) is also possible.
