Description of the blocks
4.7 MMRevDhl motor block
Table 4- 96
Feature2.Bit
Feature2.Bit3
Feature2.Bit4
Feature2.Bit5
Feature2.Bit8
Feature2.Bit10
Feature2.Bit16
The default setting is 0 in each case.
4.7.3

Output signal for ready to start

The
Readiness to start is output if the following conditions are fulfilled:
● No general fault is pending.
● No interlock is active
● No forcing of operating states and the setting value is active
● No rapid stop is active
● The block is in automatic mode
● The waiting time for the restart must have elapsed
4.7.4

Resetting of the block

Resetting the block is necessary if an interlock occurred via the input
error ("runtime" or "control") has occurred.
The
automatic commands.
The block can be reset in different ways:
● Resetting by interconnection (
● Resetting by the operator via pushbutton in the faceplate (
● Resetting by a 0-1 edge transition of the corresponding automatic or local signal (except
for motor protection).
To reset via the faceplate, the operator must have the appropriate authorization (
After a reset, the
204
Meaning of Feature2.Bits
Meaning
Control priority in the event of an invalid input command (Page 91)
Setting switch or button mode for local commands (Page 91)
Evaluation of the signal status of the interlock signals (Page 92)
Forcing operating modes in the "Local" mode (Page 93)
Considering bad quality of automatic commands or external values
(Page 93)
Separate interlock for each direction or position (Page 93)
output parameter displays whether a start is possible in AUTO mode.
RdyToStart = 1
output signals if resetting is possible via the
RdyToReset
output is set for one cycle.
P_Rst
input).
RstLi
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
, , or an
Protect Trip
input parameter or via the
RstLi
input).
RstOp
OS_Perm
SIMOCODE pro PCS 7 Library V9.0
).
