Parameter
A.7 Block parameter MMRevDhl
Parameter Data format
R_StpAct STRUCT
•
•
LockAct STRUCT
•
•
GrpErr STRUCT
•
•
RdyToStart STRUCT
•
•
RdyToReset STRUCT
•
•
WarnAct STRUCT
•
•
FFwd STRUCT
•
•
Fwd STRUCT
•
•
Rev STRUCT
•
•
FRev STRUCT
•
•
P_FFwd STRUCT
•
•
P_Fwd STRUCT
•
•
280
Default setting
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
Meaning
1 = Rapid stop is active
1 = Interlock (Permit, Interlock or Protect) or Trip is active
1 = Group error is active
1 = Ready to start
1 = Ready to reset via RstLi or automatic commands
Warning Prior to Motor Start in Auto/Manual Mode
Control Output to Start Fast Forward
Control Output to Start Motor Forward
Control Output to Start Motor Reverse
Control Output to Start Fast Reverse
Pulsive Control Output to Start Motor Forward
Pulsive Control Output to Start Motor Forward
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
SIMOCODE pro PCS 7 Library V9.0
