2.4

Template Direct

This template supports the control function Direct starter.
It contains one instance each of the following blocks:
• MMOprtn
• MMMeas
• MMStat
• MMLog
Interconnections
1. Instantiate the template from the SIMOCODE pro Library.
2. Assign the input address of the SIMOCODE pro device to the textual interconnection
"Input WORD address of SIMOCODE pro Module (IW x)" for linking the parameters
PZDIn01 (SIMOCODE blocks) / PZDIn1 (FbSwtMMS) with the logical address of the
starter. Input address and Output address should be maintained same while configuring.
Reference
Description of Blocks (Page 72)
Parameter (Page 234)
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
• MotL
• FbSwtMMS
• Event16Ts
Templates
2.4 Template Direct
