4.3.23.4

MMOprtn - Process image

The Process image view displays the values for the process image inputs (PII) and the
process image outputs (PIO). Which inputs and outputs are displayed depends on the
control function selected.
Process image view
Figure 4-2
Figure 4-3
Reference
Process images for the MMOprtn block (Page 116)
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Process image view – example of overload relay
Process image view – example of direct-on-line starter
Description of the blocks
4.3 MMOprtn block
