Description of the blocks
4.1 Functions for all blocks
4.1.10

Configurable response using the Feature I/O

4.1.10.1

Start-up characteristics

The alarm messages are suppressed in the OB100 for the
warm restart, the
When in the "Out of service mode", the block will continue to be in the same mode after a
warm restart.
Number of the
Feature
Set startup characteristics
Feature bit purpose
Set the startup characteristics of the function blocks, for example, for:
● MMRevDhl
● MMOprtn
The default setting is 0.
Note
The message classes Alarm, Warning and Tolerance are not valid for user-configured
message classes. Take into consideration the validity of terms for user-configured message
classes.
Note
During 'Run-Stop-Run' transition of the CPU,the internally pending messages, non-stuck-
through messages with time stamps and auxiliary values beginning with
blocks with the startup characteristic
counter in the following cases:
• Alarm, warning or tolerance messages from the operating points (motor, valve, dosing,
controller and analog monitoring blocks)
• Feedback errors (motor and valve blocks)
This causes an outgoing message when initializing Alarm_8P in OB100 and an incoming
message after expiration of the
80
RdyToReset
bit: 0
will be reset to zero.
bit = 0 and after the expiration of the
Feature
counter on the cyclic interrupt level.
RunUpCycle
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
number of times. During
RunUpCyc
RunUpCycle
SIMOCODE pro PCS 7 Library V9.0
occur for
RunUpCycle
