Description of the blocks
4.7 MMRevDhl motor block
4.7.18

Fault handling

The following errors can be displayed for this block:
● Error numbers (Page 77)
● Mode changeover error
● Invalid input signals
4.7.19

Invalid input signals

The "Invalid input signals" error is output if there are inconsistencies between associated
inputs and outputs. For example, you cannot issue start commands and stop commands to
the motor simultaneously.
If the block algorithm detects an invalid combination of input signals, it will issue an error
number at the
if invalid input signal exist when LocalSetting value is 4.
The STANDARD view displays this error in plain text.
4.7.20

Enable for measurement and statistics

You can open the Standard view of the MMMeas and MMStat blocks using buttons in the
Maintenance view of the MMRevDhl block.
To display buttons in the faceplate, connect the
output parameter of the MMMeas and MMStat blocks in the CFC chart.
Note
Configure MMMeas and MMStat blocks in the same CFC as the MMRevDhl block.
4.7.21

Enabled operations

The operator permissions for control commands are configured in the
parameters. These are transferred to WinCC via the
The block parameters are controlled via the FBs in CFC.
The activated parameter allows the operator to enter the desired commands.
216
output, depending on the block. Dynamic monitoring error is reported
ErrorNum
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
and input parameters to an
SelFp1 SelFp2
OS_Perm
and
OS_PermOut OS_PermLog
SIMOCODE pro PCS 7 Library V9.0
structured
parameters.
