Bit assignment Diag_Sts
Table 4- 53
Auxiliary variables
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Bit assignment Diag_Sts
Diag_Sts
bit
Diag_Sts 0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Event
Group fault
General warning
Device
Bus
PLC/PCS
Motor current flowing
ON <<
ON <
OFF
ON >
ON >>
Start active
Interlocking time active
Change-over pause active
Runs in open direction
Runs in close direction
Feedback close
Feedback open
Torque close
Torque open
Cold starting (TPF) test position feedback
Operational Protection Off (OPO)
Remote mode
Emergency start executed
Cooling down period active
Pause time active
Device check active
Phase sequence 1-2-3
Phase sequence 3-2-1
DM-F enabling circuit
Description of the blocks
4.3 MMOprtn block
141
