Tieline Merlin PLUS User Manual page 38

38 Merlin PLUS WNET Manual v2.0
2. Press on the numeric keypad to toggle channel 1 on and off and press
channel 2 on and off.
3. Use the up
A channel is highlighted when selected.
4. Use the left
5. Press the RETURN
Auxiliary Input Adjustment
The codec has 1 x 6.35mm (1/4") Mic/Line level Jack on the rear panel. By default the input is Off
and can be configured by:
1. Selecting the SETTINGS
2. Navigate to Audio and press the
3. Use the arrow-down
options.
Input settings which can be adjusted include:
·
Input enable/disable.
·
Input level.
·
Input Type: High Gain Mic, Medium Gain Mic, Low Gain Mic, Unbalanced and Line Level.
·
Phantom power (15V available when enabled).
·
IGC.
Important Note: When the auxiliary input (AUX IN) is On the default mixer configuration
sends audio to all inputs. If you are not using the auxiliary input ensure it is Off to avoid
additional noise in program audio.
Ganging Audio Channels
It is possible to gang channels together and adjust the audio level of the ganged channels
simultaneously. When channels are ganged together:
·
Both channels highlight together when selected.
·
The gain setting for both channels is automatically set to match the gain level of the lowest of
the two channels when ganging is first configured.
·
If one channel is turned on when ganging is first configured then the other one will be turned
on automatically.
1. Press the SETTINGS
2. Navigate to Audio and press
3. Use the down
4. Navigate to the channels you want to gang and press the
5. Navigate to the Gang function and press the
Disabled.
6. Use the up
and down arrow buttons to navigate to the channel you want to adjust. Note:
and right arrow buttons to adjust the input levels up or down.
button to exit the screen.
button.
button to select Aux Input and press the
navigation button to highlight Input Level and press the
and down
button.
button.
.
button to toggle between Enabled or
arrow buttons to highlight and select the audio channels.
to toggle
button to view menu
button.
button.
