148 Merlin PLUS WNET Manual v2.0
with a backup connection. If you want the codec to either dial or answer only, select one of these
options and the wizard will automatically display a subset of relevant screens to allow you to
configure the codec correctly.
Configuring Merlin Peer-to-Peer Programs: Dialing
Important Notes: Before you start program configuration please note:
·
You cannot edit a program when it is currently loaded in the codec.
·
You can
program cannot be unloaded by a codec dialing in with a different type of program.
·
Some drop-down menus and settings may be greyed out intentionally depending on
features available and the transport selected (e.g. IP or ISDN).
·
It is possible to save a program at several points throughout the program wizard and
use default settings to save configuration time.
·
Failover and SmartStream PLUS redundant streaming are not available with SIP or
sessionless IP connections.
·
POTS is not supported for stereo audio stream connections.
·
To learn more about programs see the section titled
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select Program
Manager to launch the Program Manager panel.
2. Click the Create New Program button to open the wizard and:
·
Click in the text box to name the new program.
·
Select Mono/Stereo Peer-to-Peer, or if you want to use an existing program as a template,
select this option. Then click Next.
Important Note: When you decide to use an existing program as a template, the new
program inherits all the settings of the template program and you can adjust these
settings as required by continuing through the program wizard.
3. Enter a name for the Audio Stream, add a caller ID and configure the codec to dial, answer or
dial and answer. Then click Next. Note: The caller ID is used to identify calls.
lock a loaded custom program in a codec to ensure the currently loaded
About Program Dialing.
