26 Merlin PLUS with WheatNet Specifications
Input/Output Specifications
Analog Audio Inputs
Analog
Outputs
Auxiliary Input
Headphones
Out/Aux Out
Control Port In/Out
Audio
Impedance
Output Impedance
Clipping Level
A/D &
Converters
Frequency Response
at 48kHz
THD and
(Analog)
THD and
(Digital)
Analog Signal
Noise Ratio
Sample Frequencies
IP
Frequencies
Algorithms
IP
IP (uncompressed)
Data and Control Interfaces
USB
LAN
Advanced
Networking
WheatNet-IP LAN
Serial
Protocols Supported
ISDN via module
POTS via module
Advanced Networking
VLAN Tagging
Front Panel Interfaces
Display
2 x Female XLR line inputs
Audio 2 x Male XLR
1 x 6.35mm (1/4") Mic/Line level Jack on rear panel (15V phantom power
available)
1 x 6.35mm (1/4") Jack on rear panel and 1 x 6.35mm (1/4") Jack on the
front panel
Four relay inputs and four opto-isolated outputs for machine control via a
DB15 connector.
Input High Impedance > 5K ohm
<50 ohm Balanced
+22dBu (input and outputs)
D/A 24 bit
20Hz to 22kHz
Noise <0.0035% at +16dBu or -89dB unweighted
Noise <0.000056%
To >98.5dB at +22dBu, unweighted
Sample 8kHz, 16kHz, 24kHz, 32kHz, 44.1kHz, 48kHz
Tieline Music, Tieline MusicPLUS, G.711, G.722, MPEG-1 Layer 2, MP3,
LC-AAC, HE-AAC and HE-AACv2, AAC-LD, AAC-ELD, Opus, 16/24 bit
aptX Enhanced
Linear PCM16/24 bit 48kHz sampling
USB 2.0 Host port on the front panel
2 x 10/100/1000 RJ45 connectors
VLAN tagging (IEEE 802.1Q,802.1p)
1 x 10/100 RJ45 connector to distribute WheatNet-IP audio
RS232 up to 115kbps with or without CTS/RTS flow control via female DB9
connector, can be used as a proprietary data channel
Tieline, DHCP, SNMP, DNS, HTTP, IGMP, ICMP, VLAN, IPv4/v6, FEC,
SIP/SDP (EBU N/ACIP Tech 3326 compliant), RTP, I3P EBU3347
compliant, AES67
Optional via module slot
Optional via module slot
EEE 802.1Q,802.1p
I
256 x 64 monochrome LCD
