Dial Peer-to-Peer over ISDN with Quick Connect
Important Notes:
·
Click the Unload button in the Program Loader panel if a program is currently
loaded.
·
The transcriptor algorithm is for closed captioning and not normal broadcast
configurations.
1. Click the drop-down Transport menu arrow in the Quick Connect panel and select ISDN.
2. Click the drop-down Algorithm menu and select an algorithm.
3. Click the drop-down B Channels menu and select the number of channels required for this
connection.
4. Click to select the appropriate Sample Rate for the connection.
5. Click in each Destination text box in turn to enter the ISDN number for each B Channel.
6. Click the Connect button to dial.
Dial Peer-to-Peer Over POTS with Quick Connect
Important Notes:
·
Click the Unload button in the Program Loader panel if a program is currently
loaded.
·
The transcriptor algorithm is for closed captioning and not normal broadcast
configurations.
1. Click the drop-down Transport menu arrow in the Quick Connect panel and select POTS.
2. Click the drop-down Algorithm menu and select an algorithm. The connection bit rate is
configured automatically. Note: G5 POTS modems initially attempt to establish a link at the
lowest Max Bit rate setting configured in the two modules being connected. If the POTS line
doesn't support this bit rate, the modems will attempt to connect at the highest possible bit rate
to suit the prevailing line quality at each end of the link.
3. Enter the phone number in the Destination text box.
