196 Merlin PLUS WNET Manual v2.0
15. The newly created program will be displayed in the left pane within the Program Manager
panel and in the Program Loader panel.
23.14

Configure 6 x Mono Peer-to-Peer Answering Programs

A Genie Distribution codec at the studio can accept six simultaneous bidirectional mono peer-to-
peer audio stream connections from different remote codecs. The following image displays the
default audio port settings used when creating a 6 x Mono Peer-to-Peer answering program.
Remote codecs configured with corresponding audio port settings will route audio to specific
inputs/outputs of the codec as shown.
Both mono and stereo audio stream connections can be answered by the Genie Distribution codec
when using a 6 x Mono Peer-to-Peer program. To do this load and lock a 6 x Mono Peer-to-
Peer answering program in the codec at the studio. If a codec using a stereo program attempts to
connect then the studio codec will accept the call and mix the two incoming audio channels into a
single audio channel to allow a mono peer-to-peer connection.
Routing 6 Incoming Mono Audio Streams to Specific Codec Outputs
Important Notes: Before you start program configuration please note:
to 6 are 9020, 9030, 9040 and 9050. If you need to change this setting on your dialing
codec, or in your Report-IT smart phone application, this will need to be adjusted
accordingly in the answering codec.
·
You cannot edit a program when it is currently loaded in the codec.
·
Some drop-down menus and settings may be greyed out intentionally depending on
features available and the transport selected (e.g. IP or ISDN).
·
It is possible to save a program at several points throughout the program wizard and
use default settings to save configuration time.
·
You can lock a loaded custom program
program cannot be unloaded by a codec dialing in with a different program type.
·
To learn more about programs see the section titled
·
6 audio streams must be configured.
·
Failover and SmartStream PLUS redundant streaming are not available with SIP or
sessionless IP connections.
in a codec to ensure the currently loaded
About Program Dialing.
© Tieline Pty. Ltd. 2017
