Tieline Merlin PLUS User Manual page 181

10. Configure the transport settings:
For IP click the drop-down Session Protocol menu and select Tieline Codecs and
ensure the Any check-box is not selected, then click Next.
Click to configure:
ISDN settings are determined by ISDN module answering settings. For more details see
Configuring ISDN Answering.
POTS settings are determined by POTS module answering settings. For more details
see
11. After configuring all settings there are 3 options:
i. If you want to create another answering connection, select the check-box for Create
another answering connection and continue through the wizard.
ii. Click Next to configure audio stream rules.
iii. Click Save Program to save all program settings, then click Finish to exit the wizard.
The newly created program will be displayed in the left pane within the Program Manager panel
and in the Program Loader panel. This program will now allow incoming codec calls to establish 1
x Stereo Peer-to-Peer + IFB connections and stream audio according to the input/output and port
assignments indicated at the beginning of this section.
© Tieline Pty. Ltd. 2017
Important Note: When Tieline Codecs is the Session Protocol selected
(using Tieline session data), the Local Audio Port is automatically configured
as UDP audio port 9010 by default for the second audio stream.
·
Auto Jitter Adapt and the preferred auto jitter setting using the drop-down arrow for
Buffer priority. It is also possible to configure the Minimum depth and Maximum
depth of jitter over the connection. See
·
Alternatively, select a Fixed Buffer Level and enter the Jitter Depth, which must
be between 12ms and 5000ms depending on the algorithm you select.
·
Local FEC settings if required.
Configuring POTS Answering.
Merlin PLUS WNET Manual v2.0
Configuring the Jitter Buffer
181
for more details.
