Single B Channel Config
To use a single 64kbps B channel for a connection (e.g. a 1 x Mono Peer-to-Peer audio stream):
1. Open the HTML5 Toolbox Web-GUI and click Transport and then ISDN Answer.
2. Click to select a Config.
3. Select a B channel from those available and then click Save. The connection is not bonded
if only one B channel is selected.
Multiple B Channel Bonding Config
A point-to-point audio stream can also bond multiple B channels to create higher bandwidth
connections.
1. Click to select a Config.
2. Select multiple B channels in the Config. Note: In the following example, two B channels
from Module 2 have been selected within Config 2. Note that B Channel 1 in Module 1
has already been assigned in Config 1 and is therefore greyed out and unavailable in Config
2.
3. Configure the bonding setting that best suits the audio stream associated with this Config.
Bonded or Unbonded is the best setting in most situations.
Bonding Setting
Bonded or
Bond)
Bonded Only
4. Click Save to apply changes to the Config.
© Tieline Pty. Ltd. 2017
Behavior
Unbonded (May Calls using the same algorithm from the same Tieline codec,
or sessionless calls, will attempt to bond when received. Calls
using incompatible algorithms will not be bonded
Will only bond compatible algorithms. This mode will reject
incompatible calls which cannot be bonded, e.g. G.711 and
G.722
