258 Merlin PLUS WNET Manual v2.0
3. Use the down
4. Select Usage and then the appropriate control and/or streaming mode for the connection.
Next, press the
5. Select IPv4 Mode and press the
6. Select DHCP and press the
7. Use the up
then press the
Configure a Static IPv4 Address
Static IP addresses are fixed addresses which are recommended for studio installations. Using a
static IP address ensures remote codecs can connect reliably using the same IP address over time.
1. Press the SETTINGS
2. Select Network and press the
3. Use the down
4. Select Usage and then the appropriate control and/or streaming mode for the connection.
Next, press the
5. Select IPv4 Mode and press the
6. Select Static and press the
7. Navigate to IPv4 Static and enter the IP address, then press the
8. Navigate to IPv4 Subnet and enter the Subnet Mask, then press the
9. Navigate to IPv4 Gateway and enter the Gateway details, then press the
10. Use the up
then press the
11. Check the Unit Details menu to ensure the new static IP address has been entered
correctly.
IPv6 Address Assignment
There are three IPv6 settings available for each Ethernet port, a Wi-Fi connection via the USB PORT
on the codec and any VLANs which are configured.
1. Auto: An address is automatically assigned to the codec when you connect the codec to an
IPv6 router. This process is similar to how an IPv4 DHCP address is assigned.
2. Manual: Select to manually enter IPv6 address details.
3. Off: Select to ignore IPv6 address details.
Important Note: Select Off if you are not using IPv6 to connect to another device. This
ensures your codec will attempt to connect using IPv4 at all times.
To adjust this setting:
1. Press the SETTINGS
2. Select Network and press the
3. Use the down
navigation button to select ETH1, ETH2, Wi-Fi or a VLAN interface.
button.
button.
button.
navigation button to scroll to the top of the menu and select Apply Setting,
button to confirm the new settings.
button.
button.
navigation button to select ETH1, ETH2, Wi-Fi or a VLAN interface.
button.
button.
button.
navigation button to scroll to the top of the menu and select Apply Setting,
button to confirm the new settings.
button.
button.
navigation button to select ETH1, ETH2, Wi-Fi or a VLAN interface.
button.
button.
button.
