Configure Multicast Client Programs - Tieline Merlin PLUS User Manual

6. Enter the name of the audio stream connection in the text box and click Next.
7. Continue through the program wizard and configure all 6 connections, then click Save Program
to save program settings and click Finish to exit the wizard.
8. The newly created program will be displayed in the left pane within the Program Manager
panel and in the Program Loader panel.
23.15

Configure Multicast Client Programs

Important Notes: Before you commence program configuration please note:
© Tieline Pty. Ltd. 2017
Important Note: The default Merlin PLUS answering program uses audio port 9020 for
a third audio stream IP connection. Merlin PLUS default ports for mono connections 3
to 6 are 9020, 9030, 9040 and 9050. If you need to change this setting on your dialing
codec, or in your Report-IT smart phone application, this will need to be adjusted
accordingly in the answering codec.
·
Ensure all connection related settings like the port, algorithm, bit rate (etc) match
on both multicast server and client programs or they will not connect successfully.
·
You cannot edit a program when it is currently loaded in the codec.
·
You can lock a loaded custom program
program cannot be unloaded by a codec dialing in with a different program type.
·
Some drop-down menus and settings may be greyed out intentionally depending on
features available.
·
It is possible to save a program at several points throughout the program wizard
and use default settings to save configuration time.
Merlin PLUS WNET Manual v2.0
in a codec to ensure the currently loaded
203
