132 Merlin PLUS WNET Manual v2.0
2. Click to select Module 1 or Module 2.
3. Click the Edit button to configure settings.
4. Click the drop-down arrow for Accept
voice and data calls. The default setting allows Data only.
Important Note: G.711 is the algorithm used when Voice Only is selected.
5. Click the drop-down Network arrow and select the Network Type corresponding to the
region in which you are using the codec (see
6. Click the drop-down Line Type arrow and select your preferred option. Ask your Telco
whether your ISDN line is Point-to-Point or Point-to-Multipoint. By default select Point-to-
Multipoint, unless your switch type is an AT&T 5ESS custom point-to-point.
7. If you are in the US enter DN and SPID numbers as required, or in other regions enter DN or
MSN numbers as required.
8. Click Save when configuration is complete.
to
select whether to allow or disallow circuit switched
ISDN Module Settings for more details).
