Important Note: To ensure the codec is added into Navigator correctly, when you add
the codec using the System 3rd Party Devices tab:
Only one codec should be added to Navigator at a time. For more information on the
WheatNet-IP
www.wheatstone.com
© Tieline Pty. Ltd. 2017
1. Ensure you use the identical Name and IP Address used to configure the device in
Razor software.
2. Ensure the codec is powered up and connected to the WheatNet-IP network.
3. After configuration the device should be displayed in the System pane in Navigator
software under a Blade.
4. Close Navigator software, remove power from the codec for 5 seconds and then
restore power.
5. Restart Navigator and test if codec sources can be routed to Blade destinations.
This is verified when green dots are displayed in the Navigator cross-point matrix.
Yellow cross-point dots indicate the Blade and Navigator haven't detected the
codec correctly. If this occurs, remove the newly added device, close Navigator
and remove power from the codec for 5 seconds. Then restore power to the codec
and add the device in Navigator again.
system
Merlin PLUS WNET Manual v2.0
download
Wheatstone
user
documentation
19
