208 Merlin PLUS WNET Manual v2.0
·
If you enter a directory name, all the files within the directory will be played back. We
recommend you save all audio files as a playlist and link to this if you want them to
play out sequentially. Please note that "M3U" is the playlist file format supported by the
codec.
·
File playback will occur automatically if the silence threshold parameters are breached;
if the codec is not connected for any reason file playback will commence. To stop file
playback open the Connections panel in the HTML5 Web-GUI, click to select the file
playback connection, then click Disconnect.
Configuring Rules
1. To configure new rules click the drop-down arrow and select the preferred option from those
available. Click the blue Plus symbol
to remove a rule.
Important Notes for Rules:
·
Rules for connecting or disconnecting an audio stream are configured in the Program
Manager panel. Rules for connecting or disconnecting a program are configured in the
Rules panel. See
·
A non-WheatNet-IP Tieline codec can be configured to trigger a logic IO in a Tieline
WheatNet-IP codec. Up to 64 logic IOs are available in Genie Distribution and Merlin
PLUS WheatNet-IP codecs, as well as 4 physical GPIOs.
·
Connection-related rules are not displayed in Answer only programs.
·
Relay reflection is not available for SIP and Multicast Client programs.
2. Click Save Program to complete configuration of the program.
3. Click Finish to exit the wizard.
4. Configure multicast server and multicast client programs and load all codecs with the
appropriate program.
Connections panel, or
multicast server program connection first and then connect multicast client codec programs
to begin receiving multicast streams.
23.16

Configuring SIP

The codec is fully EBU N/ACIP Tech 3326 compliant when connecting using SIP (Session Initiation
Protocol) to other brands of IP codecs. For more background on SIP connections and the
differences between registered and unregistered peer-to-peer SIP connections see
To configure the codec to dial over SIP using a SIP Server you will need to:
1. Register the codec to a SIP server using SIP account credentials.
2. Configure a SIP interface in the codec. Note: This SIP1 or SIP2 interface will include the
proxy and port settings, as well as the selected IP interface used to make the connection,
e.g. ETH1 or ETH2.
3. Create a SIP program
using the HTML5 Toolbox Web-GUI.
to add a new rule and click the Minus symbol
Creating Rules for more information.
Select and connect audio streams
dial the program manually
using the front panel via the Home screen, or create a SIP program
in a program using the
using the codec front panel. Dial the
About
© Tieline Pty. Ltd. 2017
SIP.
