4. Check the Rule Summary and click Create Rule to save the settings.
Rule 2: Use Control Port Inputs to Connect and Disconnect a Program
This rule is used to connect and disconnect a selected program when different codec control port
inputs are turned on.
1. Click the rule in the Rules panel titled Connect a program when an input is switched
ON and disconnect it when another input is switched ON.
2. Click the drop-down arrows to select the control port input used to connect and the
alternative input for disconnecting.
3. Click the drop-down Program arrow to select an individual program which will be connected
and disconnected by the change in the control port input states.
4. Check the Rule summary and click Create Rule to save the settings.
Rule 3: Synchronize Local Control Port Input Status with a Remote Relay
Output
Use this rule allow a local codec's control port input to change the state of a remote relay output.
1. Click the rule in the Rules panel titled Synchronize a local input to a remote relay.
2. Click the drop-down arrow to select the local control port input used to control a remote relay
output.
