13 SIP Accounts
14 SIP Filter Lists
15 SIP Interfaces
Settings Panels
There are several Settings panels which can be
opened in the Web-GUI. Each panel provides
different codec configuration settings and options.
Click to select and open each panel.
As an example, the Options panel is displayed
with a brief description of the other panels available.
Feature
1 Date and Time
2 Firmware tab
3 Licensing tab
4 Options tab
5 Reset / Backup
© Tieline Pty. Ltd. 2017
Click to open the panel and edit SIP account settings. Up to 6 SIP
accounts are supported.
Add trusted network codecs to the URI Whitelist. Add SIP URIs to
the URI Blacklist and add user agents to the User Agent Blacklist
to deny them access to the codec.
Click to open the panel and configure port, proxy and Via settings
for the SIP1 and SIP2 interfaces. The codec supports dialing over
these SIP interfaces simultaneously.
Description
Click to open the panel view and sync the codec to NTP time.
Click to open the panel; view software versions, download firmware
and perform an upgrade.
Click to open the panel; select a license file and install it in the
codec.
Click to open the panel; configure RS232 and QoS data settings,
lock a loaded user Program and adjust Session Port settings,
SNMP, the analog input PPM scale, reference level, AES Output
Clock sample rate and enable/disable the Quick Connect HTML
Web-GUI option.
Click to open the panel; reset codec default settings and perform
backup/restore of codec programs and settings.
Merlin PLUS WNET Manual v2.0
Settings panels
