Metering 6 Bidirectional Peer-to-Peer Mono Audio Streams
By default the PPMs display input (encoder) audio levels when up to 6 mono audio streams are
configured within a program. Inputs 1 to 6 are mapped to PPMs 1-6.
Adjusting Default PPM Metering
The default PPM metering settings can be adjusted via Settings > Audio > PPM Mode. The
options include:
PPM Mode
1 Program Default (default) Displays default program PPM meter settings (i.e. the
2 Input
3 Decoder
4 HP Monitor
Description
settings described previously for mono, stereo
etc.).
Maps input encoders 1 to 6 with PPM meters 1 to 6.
Maps decoders 1 to 6 with PPM meters 1 to 6.
Maps PPM meters to inputs/outputs currently selected via the
headphone monitoring function.
monitoring setting is accessed via HEADPHONE
Monitor Source > [Select audio Source].
programs
The default headphone
