Tieline Merlin PLUS User Manual page 202

202 Merlin PLUS WNET Manual v2.0
3. Configure the transport settings for this connection:
For IP click the drop-down Session Protocol menu and select Tieline Codecs and
ensure the Any check-box is not selected, then click Next.
Local Audio Port 9010 is used by default for a second IP connection.
Click to configure:
·
·
·
For ISDN settings are determined by ISDN module answering settings. For more details
see Configuring ISDN Answering.
For POTS, settings are determined by POTS module answering settings. For more
details see
4. After configuring all settings there are 2 options:
i. If you want to create another answering connection, select the check-box for Create
another answering connection and continue through the wizard.
ii. Click Next Stream to configure the next audio stream's settings.
5. Enter a name for the next Audio Stream, add a caller ID and configure the codec to Answer
only. Then click Next.
Auto Jitter Adapt and the preferred auto jitter setting using the drop-down arrow for
Buffer priority. It is also possible to configure the Minimum depth and Maximum
depth of jitter over the connection. See
Alternatively, select a Fixed Buffer Level and enter the Jitter Depth, which must
be between 12ms and 5000ms depending on the algorithm you select.
Local and Remote FEC settings if required.
Configuring POTS
Configuring the Jitter Buffer
Answering.
for more details.
