118 Merlin PLUS WNET Manual v2.0
Dial Peer-to-Peer over IP with Quick Connect
Important Notes:
·
Click the Unload button in the Program Loader panel if a program is currently
loaded.
·
The transcriptor algorithm is for closed captioning and not normal broadcast
configurations.
1. Click the drop-down Transport menu arrow in the Quick Connect panel and select IP.
2. Click the drop-down Algorithm menu and select an algorithm.
3. Click the select the appropriate Sample Rate and Bit Rate for the connection. Note: If only one
sample rate is available this will be automatically selected.
4. Click in the Destination text box and enter the IP address of the destination codec.
5. Click the Connect button to dial.
