Important Notes for Rules:
·
Rules for connecting or disconnecting an audio stream are configured in the Program
Manager panel. Rules for connecting or disconnecting a program are configured in the
Rules panel. See
·
A non-WheatNet-IP Tieline codec can be configured to trigger a logic IO in a Tieline
WheatNet-IP codec. Up to 64 logic IOs are available in Genie Distribution and Merlin
PLUS WheatNet-IP codecs, as well as 4 physical GPIOs.
·
Connection-related rules are not displayed in Answer only programs.
·
Relay reflection is not available for SIP and Multicast Client programs.
15. Click Save Program to save the program.
16. Click Finish to exit the wizard.
17. The newly created program will be displayed in the left pane within the Program Manager
panel and in the Program Loader panel.
using the Connections panel, or
23.18

Configure Multiple Stream SIP Programs

To configure a multiple stream SIP program simply create a new program and configure each SIP
audio stream as you would for a single SIP Peer-to-Peer program. In the following example a 2 x
Mono Peer-to-Peer dial and answer program is being configured.
Configuring a 2 x Mono Peer-to-Peer SIP Program
Important Notes: Before you start program configuration please note:
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select Program
Manager to launch the Program Manager panel.
2. Click the New Program button to open the wizard and:
·
Click in the text box to name the new program.
·
Select 2 x Mono Peer-to-Peer, or if you want to use an existing program as a template,
select this option. Then click Next.
© Tieline Pty. Ltd. 2017
Creating Rules
·
You cannot edit a program when it is currently loaded in the codec.
·
Some drop-down menus and settings may be greyed out intentionally depending on
features available.
·
Failover and SmartStream PLUS redundant streaming are not available with SIP
connections.
·
To learn more about programs see the section titled
Dialing.Remember to lock an answering program in a codec when answering
multiple SIP calls.
·
Ensure the appropriate TCP and UDP audio ports are open in your firewall to allow
SIP audio streams to connect. See
information.
Merlin PLUS WNET Manual v2.0
for more information.
Select and connect audio streams
dial the program manually
Installing the Codec at the Studio
in a program
using the codec front panel.
About Program
219
