Tieline Merlin PLUS User Manual page 163

10. Configure the transport settings:
For IP click the drop-down Session Protocol menu and select Tieline Codecs and
ensure the Any check-box is not selected.
Click Next to specify individual algorithm, jitter buffer and FEC settings, or create another
answering connection. Click to configure:
ISDN module answering settings are used if you select ISDN as the connection transport.
For more details see Configuring ISDN Answering.
POTS module answering settings are used if you select POTS as the connection
transport. For more details see
11. Continue through the steps in the wizard to complete configuration in the same way as the
first connection was configured. Click Save Program at the end of this process. The newly
created program will be displayed in the left pane within the Program Manager panel and
in the Program Loader panel.
Connections panel, or
When this program is loaded, any Tieline G3 codec dialing in using IP1 (using default Tieline IP port
settings) will be routed to output 1. A codec dialing in using IP2 will be routed to output 2.
© Tieline Pty. Ltd. 2017
Important Note: When Tieline Codecs is the Session Protocol selected
(using Tieline session data), the Local Audio Port is automatically configured
as UDP audio port 9010 by default for the second audio stream connection.
Click to deselect the Automatic check-box to adjust this setting. A codec
dialing this connection and using the port specified will always be routed to
output 2 on the codec receiving the call.
·
Auto Jitter Adapt and the preferred auto jitter setting using the drop-down arrow for
Buffer priority. It is also possible to configure the Minimum depth and Maximum
depth of jitter over the connection. See
·
Alternatively, select a Fixed Buffer Level and enter the Jitter Depth, which must
be between 12ms and 5000ms depending on the algorithm you select.
·
Local FEC settings if required.
dial a program manually
Merlin PLUS WNET Manual v2.0
Configuring the Jitter Buffer
Configuring POTS Answering.
Select and connect audio streams
using the codec front panel.
163
for more details.
in a program using the
