Configure 6 x Mono Peer-to-Peer Answering Programs

23.13
It is possible for a Merlin PLUS codec at the studio to create six simultaneous bidirectional mono
peer-to-peer audio stream connections with different remote codecs or smartphones using the
Report-IT app. The following image displays the default audio port settings used when creating a 6 x
Mono Peer-to-Peer Program. Remote codecs configured with corresponding audio port settings will
route audio to specific inputs/outputs of the Merlin PLUS codec as shown.
Select the 6 x Mono Peer-to-Peer option from the drop-down menu in the first screen of the
program wizard to configure a program allowing up to six mono audio stream connections with
different IP codecs or smartphones using Report-IT.
In nearly all situations the studio codec will receive all calls. As a result, the following program
wizard procedure displays the various configuration screens to configure an answering connection
for each incoming call from up to 6 different devices.
Both mono and stereo audio stream connections can be answered by a Merlin PLUS codec when
using a 6 x Mono Peer-to-Peer program. To do this load and lock a 6 x Mono Peer-to-Peer
answering program in a Merlin PLUS codec at the studio. If a codec using a stereo program
attempts to connect then the studio codec will accept the call and mix the two incoming audio
channels into a single audio channel to allow a mono peer-to-peer connection.
See Configuring Merlin Point-to-Point Programs
program wizard.
© Tieline Pty. Ltd. 2017
Merlin PLUS WNET Manual v2.0
for more details about individual settings within the
189
