1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select
Program Manager to launch the Program Manager panel.
2. Click the New Program button to open the wizard and:
·
Click in the text box to name the new program.
·
Select 6 x Mono Peer-to-Peer, or if you want to use an existing program as a
template, select this option. Then click Next.
3. Enter a name for the first Audio Stream, add a caller ID and configure the codec to
Answer only. Then click Next.
Note: if the codec you are configuring needs to dial connections as well as answer, you can select
Dial or answer and configure both dialing and answering connections. For the purposes of this
example dialing is excluded.
Routing Type Options:
Default
Deterministic
© Tieline Pty. Ltd. 2017
No Dial Route or Answer Route is configured. An incoming call will be
routed to an audio stream on a first-come, first-served basis in a multi-
stream program. Note: By default IP streams are routed using audio
ports.
Select a Dial Route or Answer Route to configure deterministic routing
of multiple audio streams using transports like ISDN or POTS. Use of
Dial and Answer Routes is not necessary over IP. See
Answering or Configuring POTS Answering
Merlin PLUS WNET Manual v2.0
for more information.
197
Configuring ISDN
