6. The Static IP address menu is revealed after DHCP is disabled. Use the navigation buttons
to select IPv4 Static IP and press
7. Use the numeric KEYPAD to enter the IP address and press
use the * or # buttons to enter the periods in the IP address and use the RETURN
button to delete any numbers already entered.
8. Enter changes to the IPv4 Subnet (Subnet Mask) or IPv4 Gateway (Default Gateway) in
the same way if they are required (check with your network administrator for these settings).
9. After all changes have been made use the navigation buttons to scroll to the top of the menu
and select Apply Setting, then press the OK button to save all changes.
10. From the Home screen select Settings > Unit > Eth in the codec menus to ensure the
new static IP address has been entered correctly.
Configuring a Static IP Address in Commander G3 and i-Mix G3 Codecs
To set up a static IP address in Commander G3 and i-Mix G3 codecs select Menu >
Configuration > Advanced > LAN settings > IP Setup > Setup > Static > IP Address >
[enter IP address] > press OK > Subnet Mask [enter Subnet Mask] > press OK > Gateway
[enter Gateway] > press OK > reboot the codec.
Record IP Address Details
IPv4 Static IP Address
IP Address
Subnet Mask
Default Gateway
IPv6 Mode: Manual
IP Address
IPv6 Prefix Size
IPv6 Gateway
Getting Connected
Once the studio codec is configured you are now ready to receive an incoming call from the remote
codec over the internet. Always dial from the field codec to the studio codec over the internet unless
the remote codec is assigned a public static IP address and you know this address.
© Tieline Pty. Ltd. 2017
Merlin PLUS WNET Manual v2.0
.
. .
. .
. .
(Bridge-IT, Genie and Merlin codecs only)
: :
:
: :
:
to store the setting. Note:
.
.
.
: : :
: : :
