8 Menu Navigation in Merlin PLUS with WheatNet
All main codec menus can be launched from the Home screen which includes:
Features
1 Screen Name
2 Connect
3 Cxns
4 Programs
5 Settings
Press the RETURN
button to return to the Home screen from any menu.
If a complete menu cannot be viewed on a single codec screen, arrows on the right hand side of the
screen indicate that the current menu has options below and/or above the visible items. Use the
navigation arrows to scroll up and down.
Features
1 Up Arrow
2 Down Arrow
© Tieline Pty. Ltd. 2017
Codec Home Screen Elements
The name of the current screen
Select to connect and adjust connection settings
Displays the number of current connections and connection details
View and edit Program configurations
Select to configure codec settings
button to navigate backwards through menus, or press the HOME
Codec Home Screen Elements
Arrow indicating menus can scroll upwards
Arrow indicating menus can scroll downwards
