16 Merlin PLUS WNET Manual v2.0
Configure the WheatNet-IP Card's IP Address
This process will configure the WheatNet-IP card inside the Merlin PLUS codec with a different IP
address from the default of 192.168.87.240. Note: resetting factory defaults on the codec will not
reset any WheatNet-IP card settings configured by the Razor Setup Tool.
1. Launch the Razor Setup Tool software.
2. Select Hardware > Assign IP Address.
3. Enter the MAC Address of the WheatNet-IP card in the codec. This is displayed on a label
on the rear of the codec near the WNET Audio connector. Then name the codec, add the IP
address details for your WheatNet-IP network and click START. Note: By default each
WheatNet-IP device is given an IP address in the 192.168.87.xxx range.
4. Reboot the codec and click OK when the following dialog appears.
5. The following dialog should appear to confirm the WheatNet-IP card in the codec has been
configured. Click STOP to close the dialog.
