5
GPS OPERATION
Checking your location (Continued)

D TX format: D-PRS Position (Mobile)

Displays the following items when the caller's TX
format is D-PRS Position (Mobile).
Displays the caller's direction
Compass
from your location
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based
GL on the caller's latitude and
longitude.
ALT Displays the caller's altitude
Displays the caller's distance
DST
from your location
Displays the caller's course over
COURSE
ground
SPEED Displays the caller's speed
Displays the caller's D-PRS
Symbol
symbol
Displays the time that the caller
GPS Time Stamp
acquired the position data.
Displays the caller's call sign
Call sign
(with SSID)

D TX format: D-PRS Position (Base)

Displays the following items when the caller's TX
format is D-PRS Position (Base).
Compass
Latitude
Longitude
GL
ALT
DST
POWER
HEIGHT
GAIN
DIRECT
Symbol
GPS Time Stamp
Call sign
5-6
Displays the caller's direction
from your location
Displays the caller's latitude
Displays the caller's longitude
Displays the grid locator based
on the caller's latitude and
longitude.
Displays the caller's altitude
Displays the caller's distance
from your location
Displays the caller's TX power
level
Displays the height of the caller's
antenna
Displays the gain of the caller's
antenna
Displays the direction the caller's
antenna was pointing
Displays the caller's D-PRS
symbol
Displays the time that the caller
acquired the position data.
Displays the caller's call sign
(with SSID)
