MENU SCREEN

Display items

LCD Backlight Brightness
Display > LCD Backlight Brightness
Set the LCD backlight brightness level to between 1
(Dark) and 4 (Bright).
LCD Backlight Color
Display > LCD Backlight Color
Set the LCD backlight color to between White, Amber,
Green, and Blue.
Key Backlight Brightness
Display > Key Backlight Brightness
Selects the key backlight brightness level to between
1 (Dark) and 4 (Bright).
Key Backlight Color
Display > Key Backlight Color
Selects the key backlight color to between White,
Amber, Green, and Blue.
Night Time Setting
Display > Backlight Night Time Setting >
Night Time Setting
Select whether or not to reduce the backlight
brightness for the nighttime operation.
You can set the nighttime operation start or stop time
with "Night Time Start" or "Night Time End."
• OFF: Does not reduce the backlight brightness.
• ON: Reduces the backlight brightness.
Brightness
Display > Backlight Night Time Setting > Brightness
Select the backlight brightness level for the nighttime
operation between 1 (Dark) and 4 (Bright).
Night Time Start
Display > Backlight Night Time Setting >
Night Time Start
Set the start time for the nighttime operation to
between 0:00 and 23:59.
Night Time End
Display > Backlight Night Time Setting >
Night Time End
Set the end time for the nighttime operation to
between 0:00 and 23:59.
(Default: 4) Auto Dimmer
Display > Auto Dimmer Setting > Auto Dimmer
This function sets the Auto Dimmer operation for the
display backlight.
• OFF: Auto Dimmer function is turned OFF.
(Default: White)
• Auto-OFF:
(Default: 4)
• Auto-1 to Auto-3:
(Default: White)
Auto Dimmer Timer
Display > Auto Dimmer Setting >
Auto Dimmer Timer
Set the backlight lighting period of time to between 5
and 10 seconds.
(Default: OFF)
• 5sec: The Auto dimmer function automatically
• 10sec: The Auto dimmer function automatically
Auto Dimmer Cancel (PTT)
Display > Auto Dimmer Setting >
Auto Dimmer Cancel (PTT)
Select the transceiver operation when [PTT] is pushed
while the Auto Dimmer is activated.
(Default: 2)
• OFF: Pushing [PTT] transmits a signal without
• ON:
(Default: 18:00)
Auto Dimmer Cancel (DV RX)
Display > Auto Dimmer Setting >
Auto Dimmer Cancel (DV RX)
Select the transceiver operation when receiving a DV
signal while the Auto Dimmer is activated.
(Default: 6:00)
• OFF: Receiving a DV signal displays the RX screen
• ON:
9-62
The display backlight is turned ON continuously
while the transceiver is turned ON.
The display backlight is automatically turned
ON when operating the transceiver. The
backlight is automatically turned OFF after the
set time of inactivity in the Auto Dimmer Timer.
The display backlight is automatically turned ON
when operating the transceiver. The backlight
automatically returns to the 1 ~ 3 set level after
the Auto Dimmer Timer set time ends.
activates after 5 seconds of inactivity.
activates after 10 seconds of inactivity.
turning OFF the Auto Dimmer when the Auto
Dimmer is activated.
Pushing [PTT] turns OFF the Auto Dimmer
and then transmits a signal when the Auto
Dimmer is activated.
without turning OFF the Auto Dimmer when
the Auto Dimmer is activated.
Receiving a DV signal turns OFF the Auto
Dimmer and then displays the RX screen
when the Auto Dimmer is activated.
(Default: OFF)
(Default: 5sec)
(Default: OFF)
(Default: OFF)
