10
OTHER FUNCTIONS
Remote jack (CI-V) information (Continued)
GPS/D-PRS data— Position
Command: 20 03 01, 20 03 02
q ~ o
!0 !1
0 0 X X • • • X X X X X X X X
Data number
q ~ o: Call sign/SSID
*9 ASCII characters (A–Z, 0–9, /, -, space)
!0 , !1 : Symbol
*2 ASCII characters (00h–EFh)
!2 ~ !6 : Latitude (ddºmm.mmm format)
!7 ~ @2 : Longitude (dddºmm.mmm format)
@3 ~ @6 : Altitude (0.1 meter steps)
@7 , @8 : Course (1 degree steps)
@9 ~ #1 : Speed (0.1 km/h steps)
#2 ~ #8 : Date (UTC: yyyymmddHHMMSS)
* y: Year, m: Month, d: Day, H: Hour, M: Minute,
S: Second
#9 : Power (see the table to the right)
$0 : Height (see the table to the right)
$1 : Gain (see the table to the right)
$2 : Directivity (see the table to the right)
GPS/D-PRS data— Object
Command: 20 03 01, 20 03 02
q ~ o
!0 !1
0 1 X X X X X X X X X X
• • •
Data number
q ~ o: Call sign/SSID
*9 ASCII characters (A–Z, 0–9, /, -, space)
!0 , !1 : Symbol
*2 ASCII characters (00h–EFh)
!2 ~ !6 : Latitude (ddºmm.mmm format)
!7 ~ @2 : Longitude (dddºmm.mmm format)
@3 ~ @6 : Altitude (0.1 meter steps)
@7 , @8 : Course (1 degree steps)
@9 ~ #1 : Speed (0.1 km/h steps)
#2 ~ #8 : Date (UTC: yyyymmddHHMMSS)
* y: Year, m: Month, d: Day, H: Hour, M: Minute,
S: Second
#9 : Power (see the table to the right)
$0 : Height (see the table to the right)
$1 : Gain (see the table to the right)
$2 : Directivity (see the table to the right)
$3 ~ %1 : Name
*9 ASCII characters (00h–EFh)
%2 : Type (1=Live, 0=Killed)
!2 ~ !6 !7 ~ @2
• • • X X X X • • • X X X X
!2 ~ !6 !7 ~ @2
X X X X X X X X
• • • • • •
@3 ~ @6 @9 ~ #1
@7 @8
• • • X X X X X X X X • • •
Power
Data
(W)
0 0
1 1
2 4
3 9
4 16
5 25
6 36
7 49 390/1280
8 64 780/2560
9 81 1561/5120
@3 ~ @6 @9 ~ #1
@7 @8
X X X X X X X X
• • • • • •
Power
Data
(W)
0 0
1 1
2 4
3 9
4 16
5 25
6 36
7 49 390/1280
8 64 780/2560
9 81 1561/5120
10-24
#2 ~ #8
#9 $0 $1 $2
X X X X • • • X X X X X X X X X X
Height Gain Directivity
(m/ft) (dB)
3/10 0 Omni-direction
6/20 1
12/40 2
24/80 3 135º SE
49/160 4
98/320 5 225º SW
195/640 6
7 315º NW
8
9
#2 ~ #8
#9 $0 $1
X X X X X X X X X X X X
• • •
$3 ~ %1
$2
X X X X • • •
Height Gain Directivity
(m/ft) (dB)
3/10 0 Omni-direction
6/20 1
12/40 2
24/80 3 135º SE
49/160 4
98/320 5 225º SW
195/640 6
7 315º NW
8
9
(deg)
45º NE
90º E
180º S
270º W
360º N
—
%2
X X X X
(deg)
45º NE
90º E
180º S
270º W
360º N
—
