9
MENU SCREEN
GPS items (Continued)
Item Name
GPS > GPS TX Mode > D-PRS > TX Format > Item >
Item Name
Enter an Item name of up to 9 characters.
Data Type
GPS > GPS TX Mode > D-PRS > TX Format > Item >
Data Type
Set the Item's status.
• Live Item: The Item is valid.
• Killed Item: The Item is invalid.
Symbol
GPS > GPS TX Mode > D-PRS > TX Format > Item >
Symbol
The symbol is an icon which represents Item's means
of transportation or location. The saved symbol is
transmitted along with the position data while in the
D-PRS mode.
See page 9-25 for the s
ymbol list.
Editing a symbol
1. Push [QUICK].
2. Rotate [DIAL] to select "Direct Input," then push
[ï].
3. Push [MW] to move the cursor to the second digit,
or push [MODE] to move the cursor to the first
digit.
4. Rotate [DIAL] to select a character or symbol to
the selected digit.
Selectable characters and symbols
<For the first digit>
/, \, 0 to 9, A to Z
<For the second digit>
A to Z, a to z, 0 to 9, ! " # $ % & ' ( ) * +
, - . / : ; < = > ? @ [ \ ] ^ _ ` { | } ˜
5. Push [ï] to set the symbol.
Selecting a preset symbol
1. On the "Symbol" screen, rotate [DIAL] to select
the symbol.
2. Push [ï] to set the symbol.
(Default: Live Item)
(Default: Radio)
9-31
Comment
GPS > GPS TX Mode > D-PRS > TX Format > Item >
Comment
Enter a comment.
The number of characters you can enter differs,
depending on the Data Extension and Altitude data
entry.
Data Extension
OFF
OFF
Course/Speed
Course/Speed
Power/Height/Gain/Directivity
Power/Height/Gain/Directivity Entered
The symbol " " shows the transmittable comment
range. Please note that the characters that exceed the
range will not be transmitted.
Transmittable comment range display
(In case of up to 28 characters)
Characters
Altitude entered
(maximum)
— 43 (Default)
Entered 35
— 36
Entered 28
— 36
28
