10
GPS OPERATION
■ Checking GPS Position (Continued)

D TX format: D-PRS Position (Mobile)

The following items are displayed when the caller's TX
format is D-PRS Position (Mobile).
Displays the caller's direction from
Compass
your position
Symbol Displays the caller's D-PRS symbol
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on the
GL
caller's latitude and longitude.
ALT Displays the caller's altitude
Displays the caller's distance from
DST
your position
Displays the caller's call sign (with
Call sign
SSID)
Displays the caller's direction over
COURSE
ground
SPEED Displays the caller's speed
Displays the time that the caller
GPS Time Stamp
acquired the position data.

D TX format: D-PRS Position (Base)

The following items are displayed when the caller's TX
format is D-PRS Position (Base).
Compass
Symbol
Latitude
Longitude
GL
ALT
DST
Call sign
POWER
HEIGHT
GAIN
DIRECT
GPS Time Stamp
10-7
Displays the caller's direction from
your position
Displays the caller's D-PRS symbol
Displays the caller's latitude
Displays the caller's longitude
Displays the grid locator based on the
caller's latitude and longitude.
Displays the caller's altitude
Displays the caller's distance from
your position
Displays the caller's call sign (with
SSID)
Displays the caller's TX power level
Displays the height of caller's antenna
Displays the gain of caller's antenna
Displays the direction the caller's an-
tenna was pointing
Displays the time that the caller
acquired the position data.
