9
MENU SCREEN
GPS items (Continued)
SSID
GPS > GPS TX Mode > D-PRS > TX Format >
Position > SSID
Select an SSID based on APRS
sign, to show your operating style to other stations.
The addition methods of the SSID may differ,
depending on whether the call sign includes a space
or not.
• ---: The space in call sign is converted to "-."
If no text is entered after the space, the
space will be deleted, and the space is not
converted to "-."
Example: JA3YUA → JA3YUA
JA3YUA A → JA3YUA-A
• (-0): No SSID is added. If a call sign includes a
space, any text or digit after the space will be
deleted.
Example: JA3YUA → JA3YUA
JA3YUA A → JA3YUA
• -1~-15: Adds an SSID of -1 to -15 to your call sign.
Example: SSID is "-9."
JA3YUA → JA3YUA-9
JA3YUA A → JA3YUA-9
• -A~-Z: Adds an SSID of -A to -Z to your call sign.
Example: SSID is "-Z."
JA3YUA → JA3YUA-Z
JA3YUA A → JA3YUA-Z
About the SSID
To assist in identifying a station's type, designated
call sign SSIDs are used in D-PRS (or APRS
according to a common guideline. The guideline may
be changed when the infrastructure environment,
such as a product or network, is changed. Please
check the latest guideline in the web site related to
D-PRS and APRS ® , and correctly set.
(Default: - --)
®
to add to your call
® ),
9-26
Comment
GPS > GPS TX Mode > D-PRS > TX Format >
Position > Comment
Enter a comment to transmit it with the D-PRS
position data.
You can enter up to four comments.
The number of characters you can enter differs,
depending on the Data Extension and Altitude
settings.
Data Extension
OFF
OFF
Course/Speed
Course/Speed
Power/Height/Gain/Directivity
Power/Height/Gain/Directivity
The symbol " " displays the transmittable comment
range. Please note that the characters that exceed the
range will not be transmitted.
Transmittable comment range display
(In case of up to 28 characters)
Time Stamp
GPS > GPS TX Mode > D-PRS > TX Format >
Position > Time Stamp
Sets the transmitting time stamp type to DHM, HMS or
OFF.
The time stamp is transmitted along with the position
data in the D-PRS mode, and UTC (Universal Time
Coordinated) time is used.
• OFF: Does not transmit the time information.
• DHM: Transmits the time stamp in the Day, Hour,
and Minute format.
• HMS: Transmits the time stamp in the Hour, Minute,
and Second format.
When your location is manually set, time stamp data
cannot be transmitted.
Characters
Altitude
entered (Max.)
43 (Default)
OFF
35
ON
36
OFF
28
ON
36
OFF
28
ON
(Default: OFF)
