9
MENU SCREEN
Menu items and Default settings
NOTE: The default settings shown in bold letters below are for the USA version.
The default settings may differ, depending on your transceiver version.
DUP/TONE...
Offset Freq
Repeater Tone
TSQL Freq
Tone Burst
DTCS Code
DTCS Polarity
Digital Code
Manage Memory
Memory CH
Call CH
Scan
Pause Timer
Resume Timer
Temporary Skip Timer
Program Skip
Bank Link
Program Scan Edge
Program Link
See page 9-19 for details of the preset values.
* 1 The default value may differ, depending on the frequency band and the transceiver version.
* 2 The default value may differ, depending on the transceiver version.
Settings to access repeaters.
0.000~0.600.00* 1 ~59.995 MHz
67.0~88.5~254.1 Hz
67.0~88.5~254.1 Hz
OFF or ON
023~754
Both N, TN-RR, TR-RN, or
Both R
00~99
Manages your Memory or Call channel data.
ALL, A~Z
C0/C1(144):146.010 FM*
C0/C1(430):440.000 FM*
Set scan options.
2sec~10sec~20sec, or HOLD
0sec~2sec~5sec, or HOLD
5min, 10min, or 15min
OFF or ON
A: ✔ ~Z: ✔
00~24
9-3
Sets the frequency offset for duplex (repeater)
operation.
Selects a tone frequency used to access the
repeaters.
Selects a tone frequency for the Tone Squelch
or the Pocket Beep function.
Turns the Tone Burst function ON or OFF.
This function is used to suppress the RX
squelch tail noise in the FM mode, if you
transmit a signal which superimposes the
CTCSS tone or subaudible tone.
Selects a DTCS (both encoder/decoder)
code for DTCS Squelch or the Pocket Beep
function.
Selects the DTCS polarity for the DTCS
Squelch or the Pocket Beep function.
Selects a digital code for the Digital Code
Squelch function.
Manages the Memory channels.
2 Manages the Call channels.
2
Selects the Scan Pause time. When receiving
signals, the scan pauses according to this set
period of time.
Selects the Scan Resume time from a pause
after the received signal disappears.
Selects the Temporary Skip time. When the
time is set, specified frequencies are skipped
for this set period of time during a scan.
Turns the Program Skip Scan function ON or
OFF for a VFO mode scan.
Selects banks to be scanned during a Bank
Link Scan.
Sets the frequency ranges for a Program
scan.
Sets the Link function for the Program Scan
Edge channels.
