4
D-STAR OPERATION
Entering new information into the Repeater List
D Entering new information into the repeater list (Continued)
Step 15. Selecting the position data accuracy level
L When the Near Repeater Search function is not
used, or the distance between your position and a
repeater is not displayed, select "OFF," and go to
'Step 18. Setting the UTC offset.'
1. Select "POSITION," then push [ï].
2. Select the position data accuracy level, then push
[ï].
• None: Select when the repeater has no position
data.
• Approximate: Select when the entered position data is
approximate.
• Exact: Select when the entered position data is
exactly correct.
Step 16. Entering the latitude
L This item is displayed only when 'Step 15.
Selecting the position data accuracy level' is set to
"Approximate" or "Exact."
1. Select "LATITUDE," then push [ï].
• Enters the latitude data entry mode.
2. Rotate [DIAL] to enter the latitude.
L Push [MW] to move the cursor forwards, or push
[MODE] to move the cursor backwards to select a
digit to enter.
L To enter a north latitude, select "N," and to enter a
south latitude, select "S."
3. After entering, push [ï].
Step 17. Entering the longitude
L This item is displayed only when 'Step 15.
Selecting the position data accuracy level' is set to
"Approximate" or "Exact."
1. Select "LONGITUDE," then push [ï].
• Enters the longitude data entry mode.
2. Rotate [DIAL] to enter the longitude.
L Push [MW] to move the cursor forwards, or push
[MODE] to move the cursor backwards to select a
digit to enter.
L To enter an east latitude longitude, select "E," and to
enter a west longitude, select "W."
3. After entering, push [ï].
Step 18. Setting the UTC offset
L UTC (Universal Time Coordinated) offset is the
time difference between UTC and repeater local
time. This is a useful function to know the local time
of the destination repeater before you make a call.
(p. 4-42)
1. Select "UTC OFFSET," then push [ï].
• Enters the UTC offset entry mode.
2. Rotate [DIAL] to set the time difference between
UTC and the local time, then push [ï].
Step 19. Saving the repeater list
1. Select "<<Add Write>>," then push [ï].
• The confirmation dialog "Add Write?" is displayed.
2. Select <YES>, then push [ï].
• The entered contents are saved to the repeater list,
and the display returns to the selected repeater group
screen.
TIP: To cancel the entered data
1. Push [] to display "Cancel edit?" window.
2. Select <YES>, then push [ï] to cancel entry
and return to the selected repeater group
screen.
4-36
